Description

Features:

• Equip high-speed CCD with automatic vision alignment system at set, greatly improve the precision of cutting precision and operation efficiency.
• Use high-speed main shaft to cut PCB, less cutting stress, high precision, and apply to any form of PCB.
• Dual tables motion to carry out PCB cutting and placing at the same time, improve operation efficiency.
• High-efficiency patent dust-collector, low noise, easy clean and maintain.
• Operate without supplying air-compressor, stable mechanism with the high performance of output.
• Industrial IPC Window operation system not only safe and stable but also easy to learn and use.

Operational Vision:

• Diagrammatic window operating pages, easy to learn and operate.
• Directly edit the cutting programming on screen.

System Setting:

• Provides the fine tuning revise by diagrammatic machine.
• Set the related parameters of cutting.

Maintenance Program:

• Provides the fine tuning revise by diagrammatic machine.
• Windows Operational Environment: Easy to learn.

Applications:

• Equip high-speed CCD with automatic vision offset at set, special design for high precision and production PCB cutting process.
• Apply to small linking PCB such as cell-phone, digital camera, GPS, PDA and Module cutting processing.
• Extended size applies to those large PCBs of digital TV, PC mainframe, workstation, and server cutting process.
• Choice standard jig or special purpose jig to aid in PCB cutting to increase production.
• Using dual tables to place workpiece, increase production and less waiting time.
