Description
Features
- High-speed automatic cleaning. Only 4 min. from cleaning to drying.
- Clean #500 mesh screen with original technologies.
- Applicable screen size: 450x450mm or 320x320mm.
- Standard equipment of drying system by compressed air
- Gas neutralizer improves the working environment with the “phytoncide” effect.
Cleaning Ability
Specification
| Product No. | SC-A12E-320 / SC-A12E-450 |
| Outside Dimension | W 958 D 715 H 1565mm |
| Weight | 135kg |
| Power | AC100-240V 50/60Hz |
| Power Consumption | 300VA |
| Ultrasonic frequency | 40kHz |
| Ultrasonic output | 150W |
| Input Air Supply | 0.4MPa |
| Air Consumption | 600NL/min （Peak） |
| Exhaust Air Wind< | 5m/sec |
| Applicable Stencil Size | 320×320mm / 450×450mm |
| Cleaning Time | Approx. 1 minutes – ※ |
| Rinsing Time | 6 seconds |
| Drying Time | Approx. 3 minutes – ※ |
- ※Condition : using 880 × 880mm mesh screen & recommended solvent HA-1245U
