Description
- Reduce waste and good for your environment.
- Movable Sensor can set the place where Turn Table stops.
- Set cut pieces by Movable Sensor.
- Increase productivity.
- Provide consistent tape lengths.
- Accept to cut many kinds of tape.
- Clean and neat cut.
- Bobbin free, can put any size of roll.
- Change the length of tape and spacing by knob.
- Easy to change the blades without adjustments.
|
| Cut Length |
15 – 70 mm |
| Tape Width |
3 – 25 mm |
| Usable Tape |
Filament, Kapton, Acetate, Glass Cloth, Double-Sided, Plastic, Aluminum Foil, Cellophane, Masking, polyethylene, Copper Foil Cotton, Cloth, Mylar, Teflon, Paper, and more. |
| Max Outside Diameter |
150 mm |
| Fuse |
2A |
| Power Requirements |
AC 100V 50/60Hz 25W |
| Body Material |
ABS |
| Dimensions |
126 x 150 x 258 mm (W x H x D) |
| Weight |
1.9kg |
|
| *Specification are subject to change without prior notice. |
Q: How long does a blade or a blade unit last?
A: It depends on how many tapes customer cuts in a day, and what kind of tape they are cutting. We have some expectations for how long a blade or a blade unit lasts, but it depends on types of machine. Please contact us for the details.
Q: What kind of tapes can it cut?
A: Our products are designed to cut many kinds of tape, however, some of usable tapes may not cut depends on tape manufacturer. If you have decided what kind of tape to use, please feel free to contact us.
Q: Is there a demo machine for all of products?
A: We have demo machines for ZCUT-3080, ZCUT-3150, ZCUT-3250 at all times but we do not have demo machines for ZCUT-3080, 3150, 3250 which require sample tapes before an order.
